No one loves the fact that motherboard prices keep going up (except probably the motherboard makers themselves). But there’s no denying that flagship boards still pack in the most complete and most interesting collection of features, along with high-end specs in an attempt to draw in those looking for the best of the best to build their new system around. And with AMD’s new Ryzen 7000X3D CPUs arriving with impressive performance, it’s likely that more people will be looking to build rigs based around AMD’s X670E chipset.

So here we’ll be looking at a few flagship AMD boards from Asus, Gigabyte and MSI. Similar to our Z790 flagship roundup on the Intel side, we’ll detail three (of four) flagship motherboards from the B670E platform. We’ll test and discuss the MSI X670E Godlike ($1,299), Asus Crosshair X670E Extreme ($999), and the Gigabyte X670E Aorus Xtreme in detail, and also cover the notably less expensive (but flagship nonetheless) ASRock X670E Taichi ($479.99). All boards offer a premium appearance, overkill power delivery, PCIe 5.0 slots, and M.2 sockets. Are any of these worth the price? Of these, which should you choose?

The biggest difference between these boards is the price. From the sub-$500 Taichi to the nearly $1300 Godlike, there’s a huge gap from least to most expensive. The problem (for the consumer) is that aside from just price, there isn’t a $700 difference between them on any front, including performance. While some VRMs are better, even the worst (and I use that term loosely) easily handles the Ryzen 9 7950X without issue. It comes down to how many and what speed M.2 sockets you desire, if you’re OK with last-gen flagship class audio or your want the latest and greatest, and finally, 40 Gbps USB ports.

We’ll dig into all of this and more shortly to see if any of these high-end options can earn a slot on our Best Motherboards list. But it’s undeniable that the ASRock board has a fighting edge with its (comparatively) low price and impressive specifications. But first, here are the specifications for our first subject, MSI’s X670E

Specifications: MSI X670E Godlike

Inside the Box of the MSI MEG X670E Godlike

The X670E Godlike, like it’s Z790 Godlike twin, includes a slew of accessories as value adds (like the M.2 Expander card, and M-Vision Dashboard display) and things to get you started like a USB driver stick and SATA cables. Below is a complete list of the included accessories.

• M-Vision dashboard
• Wi-Fi antenna
• USB drive (drivers)
• M-Vision cable
• (3) SATA cables
• 1 to 2 RGB LED extension Y cable
• ARGB extension cable
• 1 to 3 ARGB Gen 2 extension cables
• (2) DP to Mini DP cables
• EZ Front panel cable
• Metal Dragon badge
• (4) M.2 screw/standoffs EZ M.2 clips
• Cable Stickers
• Quick Installation Guide

Design of the X670E Godlike

Image 1 of 3

After removing the board from the retail packing, one of the first things I noticed outside of the stealthy black appearance is the sheer size and weight. It’s an E-ATX board nearly 12 inches wide, so you must ensure your case supports it. A backplate protects the back, doubling as a passive heatsink for the power delivery. The all-black appearance has a brushed aluminum finish on the heatsinks and shrouds, along with tastefully implemented branding on the IO area, chipset, VRM and M.2 heatsinks. The connections on the right side of the board are oriented horizontally, which helps with cable management.

Regarding RGB lighting, here again, only the IO area is illuminated. The colors are nice and saturated, but they won’t take over the inside of your chassis. If you need more, there are four headers to add lighting. Control over the RGBs is managed through the MSI Center Software and Mystic Light. Like its Z790 twin, I like the black-with-gold accents look. It matches most build themes and gives off that high-end vibe you want with a flagship-class motherboard.

Focusing on the top half of the board, starting with the left side above the IO area, is an Illusion Lighting effect that allows the board to display two distinct patterns (MSI Gaming Dragon and symbol) in the same space. I like this better than the dot-matrix look on the ROG Extreme. The VRMs connect via heatpipe with the top heatsink using a wavy fin design to increase surface area and dissipation properties.

To the right of the socket area and just above the DRAM slots are two 8-pin EPS connectors (one required) to power your AMD CPU. The four DRAM slots below support up to 128 GB of RAM, with speeds listed to DDR5-6666+(OC) (though that’s using one DIMM). During testing, we had no issues with our ‘base’ kits (DDR5-5600 and 6000). AMD tends to top out around 6200-6400 MHz, depending on the board and memory used.

Continuing to move right and in a unique location, we hit the first (of four) M.2 sockets. Hidden under a large flat heatsink, this CPU-connected socket runs at PCIe 5.0 x4 (128 Gbps) and supports up to 80mm modules.

In the upper-right corner is the first two (of nine) 4-pin fan headers. Each header supports DC and PWM modes with varying output. The CPU fan (auto mode by default) outputs up to 2A/24W, Pump fans up to 3A/36W, and the system fan headers at 2A/12W each (though the manual says 2A/12W). In short, there’s plenty of power to support your fans or a water-cooling pump for a custom loop.

Moving down the edge, we run into the first two RGB headers (in this case, two 3-pin ARGB), a 6-pin PCIe connector for the quick charging capability, 24-pin ATX to power the board, and finally, two front panel USB 3.2 ports with one 3.2 Gen 2 (10 Gbps) and the other 3.2 Gen 2×2 (20 Gbps). Oddly, there isn’t a 40 Gbps port on this board. Although many will not utilize that much speed, the lack of one of this platform’s new features on a flagship board just feels like an odd omission.

For power delivery, this Godlike, like its Intel-based twin, also has Godlike VRMs. Power travels down from the EPS connector(s) onto a Renesas RAA229628 controller to the 24x 105A Renesas RAA22010540 SPS MOSFETs in a teamed configuration. The 2,520A available for the CPU is the most I can recall seeing on an AMD motherboard and won’t get in the way of any type of overclocking, including using liquid nitrogen. You’re limited by the cooling method, just as you are with most mid-range boards. As awesome as this is for marketing, it raises the cost of the BOM, just for bragging rights.

On the bottom half of the board, we find the rest of the M.2 sockets, several headers, connectors, and even a few switches. The audio section on the left houses a Realtek ALC4082 codec and ESS ES9280AQ combo DAC/HPA. This is the flagship codec, with a DAC and Amp combo, and one of the better audio implementations for the AM5 platform.

Moving back to the M.2 sockets, three others are hidden below the heatsinks in this area. These M.2 sockets (M.2_2-4) connect through the chipset. Each socket supports up to 80mm modules with speeds reaching PCIe 4.0 x4 (64 Gbps). If you want/need more than the four onboard M.2 sockets, you’re in luck, as MSI includes the M.2 Expander-Z Gen 5 Dual AIC. The AIC supports up to two PCIe 5.0 x4 (128 Gbps) drives when connected to a PCIe 5.0 -capable slot (PCI_E2 on this board). The Xpander card has active cooling to keep hot-running drives within spec, and it even has an activity light so you can see when the device is in action.

Shifting focus past the chipset to the right edge, we see two USB 3.2 Gen 1 (5 Gbps) connectors and eight SATA ports. SATA ports 3/4 connect through the chipset, while SATA A1/A2 connect through the ASM1061 chip, and SATA B1-B4 connect through an ASM1064 controller. The X670E Godlike supports RAID0/1 modes for SATA devices on SATA P3/4, while the NVMe drives support RAID0/1/10 modes.

If you plan on plugging in lots of drives, it’s worth mentioning here how things break down in terms of bandwidth. When the M2_4 (the PCIe 5.0 x4 socket) is populated, PCI_E2 (the second PCIe slot) is unavailable. If you’re using a SATA- or PCIe-based drive in M2_5, SATA ports 5-8 are unavailable, leaving you with just two functioning SATA ports available.

The PCIe slots mixed in among the M.2 sockets are simple. Both are reinforced and PCIe 5.0. The top slot supports up to x16 speeds, but both run at PCIe 5.0 x8 speeds when the second slot gets populated. Last, along the right edge, are two USB 3.2 Gen 1 (10 Gbps) headers and the six SATA ports.

Across the bottom of the board are several exposed headers, all vertical. You’ll find the usual, and quite a bit more: additional USB ports, RGB headers, fan headers, custom water cooling headers (for flow and temperatures), power/reset buttons, and more. Below is a complete list from left to right.

• Front panel audio
• 4-pin RGB
• JDASH1 (M-Vison)
• 6-pin PCIe power
• LED and BIOS switches
• (4) 4-pin fan/pump headers
• 2-pin waterflow header
• (2) USB 2.0 headers
• (2) 2-pin temperature sensor headers
• Power/Reset buttons
• Front panel
• 4-pin RGB

The rear IO plate on the X670E Godlike comes preinstalled to the motherboard. It has a black background with light-grey labels on the ports, making them relatively easy to read. There are a total of nine USB ports:  two Type-C (20 Gbps) and seven 3.2 Gen 2 (10 Gbps) ports. On the left are three buttons: Clear CMOS, BIOS Flash, and the Smart button. The latter is programmable, letting you do things like reset the PC, boot into Safe Mode, control fans and lighting, etc. Around the USB ports are the Marvell 10 GbE and Intel 2.5 GbE ports. Last but not least are the Wi-Fi antenna connections and the five-plug plus SPDIF audio stack.

Firmware

MSI’s BIOS for the Godlike is not much different than the Z790 Godlike we reviewed previously. The menus reside on the sides, and information up top, with a black and red background. It’s a unique look compared to the competition. For X670E, the only updates were functionality for the new processors and chipset. The color scheme is still easy to read, and the informative Easy Mode displays various information about the system and allows for some changes (boot order and XMP enabled). Though different than other UEFIs, it is easy to get around; everything has a place, and most frequently used options are readily available, not buried within sub-menus.

Image 1 of 16

Software

MSI has a single utility, MSI Center, that covers quite a bit of functionality. From hardware monitoring to RGB control with Mystic Light, there are many applets to choose from within the software and a one-stop shop to download all of the company’s utilities. I wish there were some overclocking options here, but for those looking to use the Gamebar feature, Super Charger, or any other utilities MSI offers, they will all be at your fingertips in MSI Center.

Image 1 of 5
